How to Adjust the Blade of Your Japanese Hand Plane
Before you start using your Japanese hand plane, it's essential to understand how to properly adjust the blade for smooth, precise cuts. Woodworking is an art form that thrives on accuracy, tool care, and a genuine love for creating something extraordinary. Whether you're a beginner or a seasoned woodworker, adjusting your Japanese hand plane doesn't have to be intimidating.
In this article, we'll walk you through a simple, step-by-step process to help you adjust the blade of your Japanese hand plane, ensuring optimal performance for clean, beautiful shavings every time.
Understanding the Key Parts of a Japanese Hand Plane
Before we get into how to adjust the blade of your Japanese hand plane, let's get familiar with the key components. Knowing the names and functions of each part will help you follow the adjustment process more efficiently.
・Blade (鉋身 - Kannami): The blade is the heart of the hand plane. It into the wood’s surface as the plane is drawn back and removes a fine layer of wood, leaving a smooth finish.
・Chip Breaker (裏金 - Uragane): Positioned just short of the blade’s edge, the chip breaker prevents the blade from digging too deeply into the wood. It helps maintain a clean surface even when planing against the grain and prevents tearing when passing over knots in the wood.
・Retaining Pin (押え棒 - Osaebou): This pin secures the blade and chip breaker in place, ensuring they remain correctly aligned during use.
Having a good understanding of these parts will make the adjustment process smoother and more effective.
How to Adjust a Hand Plane's De
Let's review the key terms we'll be using before we walk you through the process of adjusting the blade on your Japanese hand plane. For clarity, we'll refer to the parts of the plane as follows:
| For the Plane Body | For the Plane Blades |
| Head | Blade |
| Tail | Chip Breaker |
| Side Grooves | |
| Retaining Pin |
With these parts in mind, you're ready to learn the step-by-step process for adjusting your kanna to achieve smooth, precise cuts.
To adjust the blade, gently tap the top of the blade with a hammer to move it forward. As you do this, check the sole of the plane to see how much of the blade is protruding from the mouth. It's important to proceed gradually, making minor adjustments to ensure the blade extends evenly.
If the blade extends too far, you can tap the head of the plane body (Dai Gashira) to retract it slightly.
Never tap the center of the plane body's head with a hammer. Doing so can cause the plane's body to split or crack, damaging the tool. Always apply force carefully and with precision.
|
Pro Tip: When setting the chip breaker, make sure it does not protrude beyond the blade. We recommend using a hammer with some weight to it—around 10.6 oz (300g) or more is ideal. If you strike the blade with a hammer made from harder materials, like steel, you may notice some slight deformation at the head of the body. This won't affect performance, but if you prefer to avoid it, consider using a mallet or a hammer made from softer metals like copper or even wood. |
How to Move the Blade Backwards
The blade may extend too far beyond the sole after you've set it. Because of this, knowing how to retract the blade properly is just as important as moving it forward.
The bottom surface of the plane’s body, where it meets the wood, must be perfectly flat. Even if the blade is well-positioned, an uneven bottom will prevent the blade from making uniform contact with the wood, resulting in an uneven cut.
| Related Articles: How to Tune the Sole of Your Japanese Hand Plane |
|
Pro Tip: When tapping the plane body to move the blade, imagine you are guiding the force in the direction the blade is set. For example, if the place is facing downward, use a downward force. Avoid applying force toward the opening of the plane body (the mouth), as this can lead to the tool splitting. The best spot to tap is on either side of the head, near the edges. You can refer to the red lines marked on the image for a clear guide on where to tap. It's easier to see if you look at it against a plain white background. |
How to Straighten a Hand Plane Blade
Sometimes, the blade may not sit evenly in the plane, causing one side to protrude more than the other. You need a perfectly aligned blade for smooth, consistent cuts, so knowing how to adjust the blade's angle is essential for optimal performance.
|
Pro Tip: |
How to Adjust the Chip Breaker
The role of the chip breaker (uragane) is to prevent the blade from cutting too deeply into the wood, aiding in a smooth planing experience. To make the most of your hand plane, proper adjustment is essential. Let’s look at the steps for setting it up correctly.
|
Pro Tip: For fine adjustments, hold the plane at eye level and carefully tap the chip breaker closer to the blade, little by little. After adjusting the chip breaker, always double-check how much the blade is protruding. Sometimes, tapping the chip breaker can cause the blade to move forward too much, so you'll have to re-adjust the blade as needed. Align the blade so that it extends only about the thickness of a hair from the sole of the plane. |
How to Remove the Blade from a Japanese Hand Plane?
There will always come a time when you need to remove the blade and chip breaker, whether for sharpening or cleaning. Here, we will teach you the proper technique for safely removing these components, ensuring the longevity of your hand plane, and preventing accidental damage.
Once the blade and chip breaker are loose, carefully pull them out together, being mindful not to drop or damage the pieces.
|
Pro Tip: Avoid tapping directly toward the mouth of the plane, as this can cause the plane body to crack. We recommend tapping near the edges of the head. You can refer to the red lines marked on the image for a clear guide on where to tap. Note: Adjusting the plane blade is crucial, but even a perfectly adjusted blade won’t perform well if the plane body is warped or the blade has lost its sharpness. Be sure to check out our articles covering each of these steps to get the best results! |
